10A-80A MPPT Solar Charge Controller-MPPT Controller-DEMUDA

10A-80A MPPT Solar Charge Controller

Product introduction

The Demda MPPT Solar Charger Controller supports automatic identification of 12V/24V/48V systems and offers multiple models ranging from 10A to 80A, compatible with lead-acid, ternary lithium, and lithium iron phosphate batteries. With a maximum photovoltaic input power of 3840W and a voltage range of 12V-80V, it features MPPT maximum power point tracking for high charging efficiency. Equipped with dual USB 5V outputs, an LCD display for real-time data monitoring, and support for parallel monitoring of up to 8 devices. It includes multiple protections against overcurrent, short circuit, and overvoltage, utilizing industrial-grade chips and high-quality MOSFETs for stable operation in environments ranging from -20°C to +45°C. Easy to install and aesthetically designed, it is suitable for various applications such as residential solar systems.

Quantity:

Inquire

Add to Basket

Product details

►Product Features

MPPT Solar Charge Controller 12/24V/48V Auto Dual USB LCD Display

* MPPT solar charge controller:12/24/48V DC automatically identifying system voltage. Support 3 charging(constant current,constant voltage, floating charge). Lead-acid battery options: Sealed, Gel, Flooded, Lithium Battery: LiFePO4/ Li(NiCoMn)O2. Parameter user can reset.

* MPPT controller 10A 20A 30A 40A 50A 60A 80A. MAX.PV input power:1920-3840W(48V system),suitable for widely use home solar energy system.

* All the Various Real-time data show on one display, Convenient to check, the power supply uses ultra low power chip,reducing static standby power consumption ,reduce energy loss,Automatic temperature compensation function

* Dual USB 5V Output charge 2.4A,paralleled up to 8 units together linked by 8pin ethernet cable to make the data monitoring easy and accurate.

* Full protection:Battery reverse discharge protection,Battery reverse polarity protection,Battery under voltage protection,Overload,short-circuit protection.

►Product Features

►Product Details
